Product usage


KVVP - PVC Sheathed Insulated Shielded Control Cable - PVC insulated PVC sheathed control cables are suitable for wiring of control, signal, protection and measurement systems with rated voltages up to and including 450/750V or 0.6/1kV and below.


Product parameters


1. Product model: KVVP

2. Product name: PVC insulated PVC sheathed braided shielded control cable

3. Rated voltage: 450/750V

4. Executive standard: GB/T9330.2-2020

5. Product use: suitable for control, monitoring circuits and protection circuits with rated voltages up to and including 450/750V.

6. Use characteristics:

(1) The long-term allowable working temperature of the cable conductor: 70°C,

(2) The laying temperature of cables should not be lower than 0°C. Recommended allowable bending radius:

a. For cables without armor layer, the PVC insulated cable should not be less than 6D of the outer diameter of the cable;

b. Cables with armored or copper tape shielding structure should not be less than 12D of the outer diameter of the cable;

c. Soft PVC insulated cables with shielding layer structure should not be less than 6D of the outer diameter of the cable. (Where D is the outer diameter of the cable)

Our products are sold to more than 20 countries and regions, distributed in Europe, the Middle East, Africa, South America and Southeast Asia and other countries. Trusted and supported by our customers. Besides, we also set up many sales distributors in large and medium cities for the domestic market. Enterprise has owned the ISO 9001 international quality management system certificate, CCC certificate for China compulsory certification and national industrial product manufacture license.
